Huawei EchoLife HG8110 User Manual

5.2 WAN
This topic describes how to configure the WAN interface through the Web page.
5.2.1 WAN Configuration
l WAN Configuration - route
1. In the navigation tree on the left, choose WAN > WAN Configuration. In the pane
on the right, click New. In the dialog box that is displayed, set Mode to Route, as
shown in Figure 5-11.
Figure 5-11 WAN Configuration - route
2. Click Apply to apply the configuration.
Table 5-1 describes the parameters related to the WAN in route mode.
Table 5-1 Parameters related to the WAN in route mode
Parameter
Description
Enable Indicates whether to enable the WAN
connection.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 5 Web Page Reference
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
307
