Service
Classificati
on
Item Data Remarks
QoS (DBA) HSI service
l Profile type: Type4
l Maximum bandwidth: 100
Mbit/s
l T-CONT ID: 4
l DBA is used to
control the
upstream
bandwidth of the
ONT. DBA
profiles are
bound to
TCONTs.
Different
TCONTs are
planned for
different
bandwidth
assurance types.
l Generally, the
service with a
high priority
adopts a fixed
bandwidth or an
assured
bandwidth, and
the service with a
low priority
adopts the
maximum
bandwidth or
best effort.
IPTV service
l Profile type: Type4
l Maximum bandwidth: 60
Mbit/s
l T-CONT ID: 3
VoIP service
l Profile type: Type3
l Assured bandwidth: 15
Mbit/s
l Maximum bandwidth: 30
Mbit/s
l T-CONT ID: 2
QoS (CAR)
HSI service Upstream and downstream
bandwidth: 4 Mbit/s
l Traffic control
can be
implemented on
the BRAS, or on
the OLT or ONT
by using port rate
limitation or
using a traffic
profile to limit
the upstream and
downstream
traffic.
l Generally, in the
case of FTTH,
limit the rate on
the OLT.
IPTV service
No rate limitation in the
upstream and downstream
directions
VoIP service No rate limitation in the
upstream and downstream
directions
IPTV
service data
Multicast protocol
l OLT: IGMP proxy
l ONT: IGMP snooping
-
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
130
