Service
Classificati
on
Item Data Remarks
Multicast version IGMP V3 IGMP v3 and IGMP
v2 are supported,
and IGMP v3 is
compatible with
IGMP v2.
Multicast program
configuration mode
Static configuration mode The OLT can also
generate a multicast
program library,
that is, dynamically
generate a program
list according to the
programs requested
by users. In this
mode, the program
list need not be
configured or
maintained;
however, the
functions such as
program
management, user
multicast bandwidth
management,
program preview,
and program prejoin
are not supported.
IP address of the
multicast server
10.10.10.10 -
Multicast program 224.1.1.10 -
VoIP service
data
MG interface (H.
248)
NOTE
The parameters of the
MG interface must be
the same as the
parameters on the
MGC. H.248 has
many negotiation
parameters, and the
parameters here are
mandatory.
IP address of the primary MGC
to which the MG interface
belongs: 200.200.200.200/24
When dual homing
is configured, the IP
address and the port
ID of the secondary
MGC must also be
configured.
Port ID of the primary MGC to
which the MG interface
belongs: 2944
l MID format: domain name
l MG domain name:
6877687714852901
Domain name is
globally unique.
This example uses
ONT's SN as the
domain name.
TID: A0 and A1 The phone numbers
of terminals A0 and
A1 are 88001234
and 88001235.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
131
