Product Number of
ETH Ports
Number of
POTS Ports
Number of
CATV Ports
HG8010 1 - -
HG8110 1 1 -
HG8240 4 2 -
HG8245 4 2 -
HG8247 4 2 1
HG8447 4 4 1
huawei(config)#ont-srvprofile gpon profile-id 10
huawei(config-gpon-srvprofile-10)#ont-port eth 4 pots 2 catv 1
huawei(config-gpon-srvprofile-10)#port vlan eth 1 10
After the configurations are complete, run the commit command to make the
configured parameters take effect.
huawei(config-gpon-srvprofile-10)#commit
huawei(config-gpon-srvprofile-10)#quit
d. (Optional) Configure an alarm profile.
– The ID of the default GPON alarm profile is 1. The thresholds of all the alarm
parameters in the default alarm profile are 0, which indicates that no alarm is
reported.
– In this example, the default alarm profile is used, and therefore the
configuration of the alarm profile is not required.
– Run the gpon alarm-profile add command to configure an alarm profile,
which is used for monitoring the performance of an activated ONT line.
4. Add an ONT on the OLT.
The ONT is connected to the GPON port of the OLT through optical fibers. The service
can be configured only after an ONT is successfully added on the OLT.
Two ONTs are connected to GPON port 0/1/1. The ONT IDs are 1 and 2, the SNs are
6877687714852900 and 6877687714852901, the management mode is OMCI, and
ONT line profile 10 and service profile 10 are bound to the two ONTs.
a. Add an ONT offline.
If the password or SN of an ONT is obtained, you can run the ont add command
to add the ONT offline.
huawei(config)#interface gpon 0/1
huawei(config-if-gpon-0/1)#ont add 1 1 sn-auth 6877687714852900 omci
ont-lineprofile-id 10 ont-srvprofile-id 10
huawei(config-if-gpon-0/1)#ont add 1 2 sn-auth 6877687714852901 omci
ont-lineprofile-id 10 ont-srvprofile-id 10
b. Automatically find an ONT.
If the password or SN of an ONT is unknown, run the port portid ont-auto-
find command in the GPON mode to enable the ONT auto-find function of the
GPON port. Then, run the ont confirm command to confirm the ONT.
huawei(config)#interface gpon 0/1
huawei(config-if-gpon-0/1)#port 1 ont-auto-find enable
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
135
