Huawei EchoLife HG8110 User Manual

Table 3-12 Data plan for connecting ONTs in the FTTH GPON access mode
Configurat
ion Item
Data Item Detailed Data Remarks
WAN port
data
HSI service
(Layer 3
routing)
l Service type: Internet
l Connection mode: routing
l VLAN ID: 10
l IP address obtainment
mode: PPPoE (user name:
iadtest@pppoe, password:
iadtest)
l 802.1p: 1
l NAT function: enable
l Bound port: LAN1 (LAN1 is
a Layer 3 LAN)
l For configuring HSI
service or Wi-Fi
service, Internet or a
combination
containing Internet
must be selected as the
service type. For
configuring VoIP
service, VoIP or a
combination
containing VoIP must
be selected as the
service type.
l The VLAN ID of the
ONT must be the same
as the user-side VLAN
ID configured on the
OLT.
l PPPoE must use the
same user name and
password as the upper-
layer BRAS.
l The HSI service
involves the Layer 2,
Layer 3 bridge and
Layer 3 routing modes.
In the Layer 2 mode, all
configurations are
required only on the
OLT. The application
mode of the Layer 3
bridge mode is similar
to the Layer 2 mode. It
is recommended that
you use the Layer 2
mode.
l The Wi-Fi service does
not support the Layer 2
mode.
VoIP service
l Service type: VoIP
l Connection mode: routing
l VLAN ID: 20
l IP address obtaining mode:
DHCP
l 802.1p: 6
Wi-Fi
service
(Layer 3
bridge)
l Service type: Internet (not
configurable)
l Connection mode: bridge
l VLAN ID: 40
l 802.1p: 1
l Bound port: SSID1
Wi-Fi
service
(Layer 3
routing)
l Service type: Internet
l Connection mode: routing
l VLAN ID: 40
l IP address Obtainment
mode: PPPoE (user name:
iadtest@pppoe, password:
iadtest)
l 802.1p: 1
l NAT function: enable
l Bound port: SSID1
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
214
