4. In the right pane, click New to add voice user 2, and configure the parameters of voice user
2 as follows:
l Line Name: A1
l Associated POTS: 2 (binding port TEL2 on the ONT)
l Select Enable Line Name to enable the voice user configuration.
5. Click Apply to apply the configuration.
NOTE
l The terminal IDs A0 and A1 must be consistent with the corresponding configuration on the MGC.
l If Associated POTS is 1, port TEL1 on the ONT is bound. If Associated POTS is 2, port TEL2 on the ONT
is bound.
Step 4 Save the configuration.
Choose System Tools > Configuration File from the navigation tree. In the right pane, click
Save Configuration.
Step 5 Restart the voice process.
In the navigation tree, choose Status > VoIP Information. In the right pane, click Restart
VoIP.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
227
