NOTE
l If the WAN interface obtains IP addresses in static or DHCP mode, choose WANIPConnection to
set the parameters of the WAN interface.
l If the WAN interface obtains IP addresses in PPPoE mode, choose WANPPPConnection to set the
parameters of the WAN interface.
Step 5 Bind a LAN port.
Choose 1X_HW_LANBIND from the navigation tree. In the right pane, set Lan1Enable to 1
to bind the WAN interface to LAN port 1.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
243
