Huawei EchoLife HG8110 User Manual

Service
Type
Item Settings Remarks
Service profile
l Name: FTTx
l Number of Pots Ports: 2
l Number of ETH Ports: 4
l Vlan Type: Translation
l C-VLAN: 100,1000
l S-VLAN: 100,1000
-
Internet
service
VLAN
l VLAN ID: 100
l Type: Smart VLAN
-
Service port
l Name: HSI
l VLAN ID: 100
l Interface Selection:
0/2/1/0/1
l Service Type: Multi-
Service VLAN
l User VLAN: 10
l Keep the upstream and
downstream settings the
same: selected
l Upstream Traffic Name:
FTTx
-
ONT value-added
services (Layer 3
routing)
l Profile Name: ONT-HSI
l Vendor ID: HWTC(2011)
l Terminal Type: 247
l Version: V1R002C06–
V1R002C07
l WAN VLAN ID: 10
l Service Type: INTERNET
l Connection Type:
IP_Routed
l Addressing Type: PPPoE
(User Name:
iadtest@pppoe, Password:
iadtest)
l Priority: 1
l NAT function: enable
l Bound port: LAN1 (LAN1
is a Layer 3 LAN)
-
IPTV
service
VLAN
l VLAN ID: 1000
l Type: Smart VLAN
-
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
33
