Test Item to Be Tested Signal Stream
Remote video
loopback
l Remote video module
l Network transmission
Camera → 3 → 5 → 6 → 9 → 10 → 6 →
5 → 4 → Monitor
Remote digital
loopback
l Remote audio and video
modules
l Network transmission
The TE30 performs remote audio and
video loopback tests simultaneously.
Network Tests
Table 13-7 Network tests
Test Item to Be Tested Signal Stream
Network IP access Endpoint → LAN or public network
Before a network test, ensure that your TE30 is connected to an IP network and IP parameters
are set correctly.
l If your TE30 is on a public network: In IP address, enter an IP address that is in a different
network segment from your TE30 IP address. Then select Start. If the test is successful,
the gateway settings and IP address of your TE30 are correct.
l If your TE30 is on a private network: In IP address, enter a public IP address. Then select
Start. If the test is successful, the gateway settings, NAT address, and IP address of your
TE30 are correct.
Remote Control Tests
Test the keys on the remote control to check whether they are functioning properly. If only some
of the keys are tested, you can exit the Remote Control Test screen by pressing and holding
on the remote control.
When all the keys are tested, the Remote Control Test screen automatically exits.
The maximum operating distance of the remote control is 15 meters. Its performance may be
affected under strong light.
If the remote control does not work, verify that:
l The TE30 is powered on.
l The positive and negative charges of the battery are connected correctly.
l The battery has sufficient power left.
l There are no special fluorescent or neon signs nearby.
HUAWEI TE30 Videoconferencing Endpoint
User Guide 13 Maintenance
Issue 01 (2013-03-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
129
