Fuse
Specifications
1FU13/2FU13
Fuse of phase L3 of monitoring board 3 or fuse of phase L1 of
monitoring board 6
1FU14/2FU14
Fuse of phase L2 of monitoring board 3 or fuse of phase L2 of
monitoring board 6
1FU15/2FU15
Fuse of phase L1 of monitoring board 3 or fuse of phase L3 of
monitoring board 6
The preceding tables use single- and dual-input scenarios as examples. The actual cabinet configurations
prevail.
Procedure
Step 1 Open the cover of the fuse terminal.
Figure 5-12 Opening the cover of the fuse terminal
(1) Cover
Step 2 Remove the blown fuse and install a new one.
Step 3 Press the cover of the fuse terminal.
----End
5.1.1.5 Replacing the Monitoring Board
Context

Tool: Phillips screwdriver

Materials: new monitoring board

Document: none
