Huawei FusionServer Pro 2298 V5 - Indicators and Buttons

1 Drive drawer ejector lever 2 Release slider of the drive
drawer ejector lever
3 Upper drive drawer 4 Mounting ear ejector lever
5 Lower drive drawer 6 Slide-out label plate (with
an SN label)
5.1.2 Indicators and Buttons
Positions
Figure 5-2 Indicators and buttons on the front panel
1 Power button/indicator 2 Health status indicator
3 10GE optical port (LOM
port 1) connection status
indicator
4 GE electrical port (LOM
port 3) connection status
indicator
5 UID button/indicator 6 Non-Maskable Interrupt
(NMI) button
7 10GE optical port (LOM
port 2) connection status
indicator
8 GE electrical port (LOM
port 4) connection status
indicator
9 Status indicators of the
drives in the front drawers
- -
Huawei FusionServer Pro 2298 V5 Server
Technical White Paper 5 Hardware Description
Issue 05 (2020-09-03) Copyright © Huawei Technologies Co., Ltd. 9
