3 Physical Structure
Figure 3-1 2298 V5 physical structure
1 Rear drives 2 Rear drive module
3 PCIe riser module 4 Standard PCIe cards
5 PSUs 6 Chassis
7 Air duct 1 8 Upper drive drawer
9 Lower drive drawer 10 Fan module bracket
11 Fan modules 12 Air duct 2
13 Heat sinks 14 Processors
15 DIMMs 16 TPM/TCM
17 Mainboard 18 OCP 2.0 mezzanine card
