PCIe Riser Module
Figure 5-22 PCIe riser module
5.7.3 PCIe Slot Description
NO TE
The PCIe slots mapping to a vacant CPU socket are unavailable.
Table 5-17 PCIe slot description
PCIe
Slot
CPU PCIe
Stand
ards
Conne
ctor
Width
Bus
Width
Port
No.
Root
Port
(B/D/
F)
Device
(B/D/
F)
Slot
Size
LOM CPU1 PCIe
3.0
x8 x8 Port1C 85/02/
0
89/00/
0
-
