Sensor Description Component
CPU N DDR VDDQ2 1.2 V DIMM voltage Mainboard
N indicates the CPU
number. The value is 1 or
2.
CPU N VSA CPU VSA voltage Mainboard
N indicates the CPU
number. The value is 1 or
2.
CPU N VCCIO CPU VCCIO voltage Mainboard
N indicates the CPU
number. The value is 1 or
2.
CPU N VMCP CPU VMCP voltage Mainboard
N indicates the CPU
number. The value is 1 or
2.
PCH VPVNN PCH VPVNN voltage Mainboard
PCH PRIM 1V05 PCH PRIM voltage Mainboard
HDD BP N STBY3.3V Drive backplane 3.3 V
voltage
Front-drive backplane
N indicates the
backplane number. The
value is 1 or 2.
HDD BP N 5V Drive backplane 5.0 V
voltage
Front-drive backplane
N indicates the
backplane number. The
value is 1 or 2.
HDD BP N 12V Drive backplane 12.0 V
voltage
Front-drive backplane
N indicates the
backplane number. The
value is 1 or 2.
CPU N VCCP CPU VCCP voltage Mainboard
CPU N DDR VPP1 CPU DDR voltage Mainboard
CPU N DDR VPP2 CPU DDR voltage Mainboard
FAN N Speed Fan speed Fan module N
N indicates the fan
module number. The
value ranges from 1 to 5.
Power Server input power PSUs
