16
Power cable hole
Signal cable hole
Outdoor unit power cable
on the side of the indoor
unit
Outdoor unit
power cable
Connecting the Power Cables to the Outdoor Units
If the outdoor unit is NetCo500-A120, connect the power cables of the two indoor units to
the QF1 and QF3 of the outdoor unit respectively.
Power
cable hole
Outdoor unit
power cable
Outdoor unit
power cable on the
side of the indoor
unit
If the indoor unit BOM number is 52274052, connect the outdoor unit power cable as shown
in the following figure.
