Huawei SUN2000-17KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
4 Installation
Issue 12 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
23
Tool
Model
Function
Level
N/A
Checks the levelness of the rear
panel.
ESD gloves
N/A
Protect operators when drilling
holes.
Safety goggles
N/A
Protect operators when drilling
holes.
Anti-dust respirator
N/A
Protects operators from dust
inhalation when drilling holes.
4.3 Determining the Installation Position
The requirements described in this section apply to both wall mounting and support mounting.
This section uses wall-mounting the SUN2000 as an example.
Comply with the following requirements when determining an appropriate position to install
the SUN2000:

Do not install the SUN2000 on flammable building materials.

Do not install the SUN2000 in an area that stores flammable or explosive materials.

Huawei SUN2000-17KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
MPPT voltage range	200 V - 1000 V
Max. input current per MPPT	26 A
Number of MPPTs	2
AC nominal power	17000 W
Operating temperature range	-25°C to +60°C
Cooling	Natural Convection
Protection rating	IP65
Max. AC power	18700 VA
Rated AC voltage	220 V / 380 V, 230 V / 400 V
