Huawei SUN2000-17KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
7 Man-Machine Interaction
Issue 12 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
66
7 Man-Machine Interaction
Context
Users can interact with the SUN2000 using the LCD or SUN2000 APP. This topic uses
operations on the LCD as an example. For details about operations on the SUN2000 APP, see
the SUN2000 APP User Manual.
7.1 Monitoring Menu Hierarchy
This section describes the hierarchy of the monitoring menus on the LCD, which facilitates
monitoring of the SUN2000.
Figure 7-1 shows the hierarchy of the Main Menu.

Huawei SUN2000-17KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
MPPT voltage range	200 V - 1000 V
Max. input current per MPPT	26 A
Number of MPPTs	2
AC nominal power	17000 W
Operating temperature range	-25°C to +60°C
Cooling	Natural Convection
Protection rating	IP65
Max. AC power	18700 VA
Rated AC voltage	220 V / 380 V, 230 V / 400 V
