Huawei SUN2000-185KTL-INH0 User Manual

Figure 4-8 Removing a security torx wrench
4.4.1 Support-mounted Installation
Support-mounted Installation
Step 1 Install the mounting bracket.
Figure 4-9 Installing the mounting bracket
NO TE
The M12x40 bolt assemblies are delivered with the SUN2000 (bound to the mounting
bracket). If the bolt assembly length does not meet the installation requirements, prepare
M12 bolt assemblies by yourself and use them together with the delivered M12 nuts.
----End
4.4.2 Wall-mounted Installation
Wall-mounted Installation
Step 1 Install the mounting bracket.
SUN2000-(175KTL-H0, 185KTL-INH0, 185KTL-H1)
User Manual 4 Installation
Issue 19 (2023-12-20) Copyright © Huawei Technologies Co., Ltd. 35
