Avoid drilling holes in the water pipes and power cables buried in the wall.
● To prevent dust inhalation or contact with eyes, wear safety goggles and an
anti-dust respirator when drilling holes.
● Clean up any dust in and around the holes using a vacuum cleaner and
measure the distance between holes. If the holes are inaccurately positioned,
drill a new set of holes.
● Level the head of the expansion sleeve with the concrete wall after removing
the bolt, spring washer, and at washer. Otherwise, the mounting bracket will
not be securely installed on the wall.
Figure 4-10 Securing the mounting bracket
----End
4.5 Installing the Inverter
Preparing for the Installation
Before installing the inverter, take it out from the packing case and move it to the
installation position.
SUN2000-(175KTL-H0, 185KTL-INH0, 185KTL-H1)
User Manual 4 Installation
Issue 19 (2023-12-20) Copyright © Huawei Technologies Co., Ltd. 36
