Huawei SUN2000-23KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
10 Technical Specifications
Issue 07 (2014-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
118
Technical
Specifications
SUN2000
-8KTL
SUN2000
-10KTL
SUN2000
-12KTL
SUN2000
-15KTL
SUN2000
-17KTL
SUN2000
-20KTL
SUN2000
-23KTL
SUN2000
-28KTL
MPP voltage
range
320 V–800 V
380
V–800 V
400 V–800 V
480 V–800 V
Rated input
voltage
620 V
Max. number of
inputs
4
6
Number of MPP
trackers
2
a
3
b
a: 2 MPPTs can work independently or work in parallel.
b: 3 MPPTs can work independently, or work in parallel, or any 2 of 3 MPPTs work in
parallel.
Output
Technical
Specifications
SUN2000
-8KTL
SUN2000
-10KTL
SUN2000
-12KTL
SUN2000
-15KTL
SUN2000
-17KTL
SUN2000
-20KTL
SUN2000
-23KTL
SUN2000
-28KTL
Rated power(230
V, 50 Hz)
8,000 VA
10,000 VA
12,000 VA
15,000 VA
17,000 VA
20,000 VA
23,000 VA
27,500 VA
Max. AC output
power (cosφ=1)
8,800 W
11,000 W
13,200 W
16,500 W
18,700 W
22,000 W
-
-
Rated output
voltage
220 V - 230 V / 380 V - 400 V, 3W + N + PE
277 V / 480
V, 3W +
PE
AC power
frequency
50 Hz/60 Hz
Max.output
current
12.8 A
16 A
19.2 A
24 A
27.2 A
32 A
33.5 A
33.5 A
Power factor
0.8 overexcited … 0.8 underexcited
Max.total
harmonic
distortion
< 3%
AC connected
Inrush current
(Peak /
Duration)
33 A / 2 ms
Max. output
short current
(Peak /
Duration)
400 A / 110 ms

Huawei SUN2000-23KTL Specifications

General

Brand	Huawei
Model	SUN2000-23KTL
Category	Inverter
Language	English
