generation system should be prepared according to the same standard. Table 5-7 lists the 568A
wire sequence standard. Table 5-8 lists the 568B wire sequence standard.
Table 5-7 568A standard
Pin
Color
1
White and green
2
Green
3
White and orange
4
Blue
5
White and blue
6
Orange
7
White and brown
8
Brown
Table 5-8 568B standard
Pin
Color
1
White and orange
2
Orange
3
White and green
4
Blue
5
White and blue
6
Green
7
White and brown
8
Brown
Connecting a Cable to the FE Network Port
Step 1 Insert the wires of the network cable to the RJ45 connector in sequence, as shown in Figure
5-38.
