Huawei SUN2000-50KTL-JPM0 - 5.7 Closing the Compartment Door

SUN2000-(50KTL-JPM0, 50KTL-JPM1, 63KTL-JPM0)
User Manual
5 Electrical Connections
Issue 01 (2018-09-30)
Copyright © Huawei Technologies Co., Ltd.
54
Figure 5-30 Bundling communications cables
Step 5 Tighten the thread-lock sealing nut and seal the cable gland.
----End
5.7 Closing the Maintenance Compartment Door
Procedure
Step 1 Install the AC terminal cover.
Figure 5-31 Installing a cover
Step 2 Retrieve the support bar.
