Huawei SUN2000-8KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
4 Installation
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
30
Figure 4-9 Securing a rear panel
Step 4 Hold the handle at the bottom of the SUN2000 with one hand and hold the end of the other
handle near the SUN2000 top with the other end, and then stand the SUN2000, as shown in
Figure 4-10. Two persons are required to install the SUN2000.
To prevent personal injury caused by a falling SUN2000, keep balance when lifting the
SUN2000 because the SUN2000 has a heavy top.
Figure 4-10 Lifting a SUN2000
Step 5 Mount the SUN2000, keeping the mounting brackets in alignment with the rear panel, as
shown in Figure 4-11.

Huawei SUN2000-8KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
Nominal AC output power	8000 W
Weight	25 kg
Operating temperature range	-25°C to +60°C
Protection rating	IP65
Max. apparent AC power	8800 VA
AC grid frequency	50 Hz / 60 Hz
Starting voltage	200 V
Number of MPPTs	2
Cooling	Natural convection
Maximum DC Input Power	12000 W
Output Frequency	50 Hz / 60 Hz
Nominal AC voltage	230 V
Operating voltage range	200 V - 1000 V
Rated Output Voltage	230 V
MPPT Voltage Range	260 V - 850 V
