Huawei SUN2000-8KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
4 Installation
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
37
To prevent personal injury, maintain balance when lifting the SUN2000 because it is
top-heavy.
Figure 4-21 Lifting the SUN2000
Step 8 Run a rope that is sufficiently weight-bearing for the SUN2000 through the lifting eyes and
hoist the SUN2000, as shown in Figure 4-22.
When hoisting the SUN2000, maintain balance to protect the SUN2000 from knocking into
the wall or other objects.

Huawei SUN2000-8KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
Nominal AC output power	8000 W
Weight	25 kg
Operating temperature range	-25°C to +60°C
Protection rating	IP65
Max. apparent AC power	8800 VA
AC grid frequency	50 Hz / 60 Hz
Starting voltage	200 V
Number of MPPTs	2
Cooling	Natural convection
Maximum DC Input Power	12000 W
Output Frequency	50 Hz / 60 Hz
Nominal AC voltage	230 V
Operating voltage range	200 V - 1000 V
Rated Output Voltage	230 V
MPPT Voltage Range	260 V - 850 V
