Do not open the host panel of the SUN2000.
Before opening the SUN2000 maintenance compartment door, turn off the downstream
AC output switch and the bottom DC switch.
Do not open the maintenance compartment door during rainfall or snowfall. If you must,
take protective measures to prevent rain or snow from entering the maintenance
compartment.
Do not leave unused screws in the maintenance compartment.
Procedure
Step 1 Remove the cover of the maintenance compartment and install a SIM card.
Figure 4-14 Installing a SIM card
Install the SIM card in the direction shown on the arrow on the card slot.
To install the SIM card, press it in place until it locks. Do not remove the 4G module when installing
the SIM card.
To remove the SIM card, push it inward and then let go to eject it.
----End
