Figure 4-76 Settings in the Internet Options dialog box
Step 3 Enter https://UPS IP address in the address box of the browser, select a language, set User
name and Password, and click Login. The system supports Internet Explorer 11 and Firefox
31.0. Table 4-5 describes the system users.
The preset UPS IP address is 192.168.0.10. You can set the UPS Ethernet IP address on the LCD or
WebUI. The value range is 1.0.0.0–223.255.255.255.
Table 4-5 User description
admin (system
administrator)
Performs all operations on the LCD and
WebUI, including system running information
browsing, system information (historical
alarms, logs, e-labels, and fault data)
exporting, parameter (system parameters and
battery parameters) setting, system control
(startup, shutdown, troubleshooting, runtime
clearing, and battery management), system
