b. On the login page, select a display language, enter a User name and Password, and
click Login.
c. On the homepage, choose Monitoring > Control, and click Inv. OFF. In the
displayed dialog box, click OK to shut down the inverter.
Figure 5-17 Shutting down the inverter
After the inverter shuts down, the UPS works in bypass mode if the bypass is
normal, as shown in Figure 5-18; the UPS supplies no power and the loads power
off if the bypass is abnormal, as shown in Figure 5-19.
Figure 5-18 Normal bypass
After you shut down the inverter, the Bypass mode alarm is displayed on the LCD.
