Setup mode
OPERATION MANUAL Chapter 4
Unistat® V2.0.0en/09.06.16//15.09
60
4.2.8.3.3 Sub-category: “VPC/Bypass”
Under this entry, you can specify whether you use a bypass or not.
PROCEDURE
 Go to the “Categories Menu”.
 Tap on the category “Temperature Control”.
 Tap on the category “TAC/Manual”.
 Tap on the sub-category “Configuration auto”.
 Tap on the sub-category “Fluid Properties”.
 Tap on the sub-category “VPC/Bypass”.
 Choose between the dialog entries “Bypass used” and “Bypass not used”.
 Confirm your choice by tapping on “OK”.
4.2.8.3.4 Sub-category: “Show Fluid”
This entry provides you with an overview of the settings entered.
PROCEDURE
 Go to the “Categories Menu”.
 Tap on the category “Temperature Control”.
 Tap on the category “TAC/Manual”.
 Tap on the sub-category “Configuration auto”.
 Tap on the sub-category “Fluid Properties”.
 Tap on the sub-category “Show Fluid”.
 Tap on “OK” after you have read/checked the entries.
4.2.8.4 Sub-category: “Display parameters”
Here you can display the set parameters in “Automatic mode”.
PROCEDURE
 Go to the “Categories Menu”.
 Tap on the category “Temperature Control”.
 Tap on the category “TAC/Manual”.
 Tap on the sub-category “Configuration auto”.
 Tap on the sub-category “Display parameters”.
 Tap on “OK” after you have read/checked the parameters.
4.2.9 Category: “Configuration manual”
Use of the “Expert mode” without a thorough knowledge of I&C technology.
MATERIAL DAMAGE TO THE APPLICATION
 Only use this mode if you have a thorough knowledge of I&C technology.
In “Expert mode”, “Configuration auto” is deactivated only “Configuration manual” is possible.
To enter settings in “Expert mode” requires in-depth knowledge of process measuring and control tech-
nology. Incorrect or insufficient settings can severely impair the function of the temperature control unit.
4.2.9.1 Sub-category: “Change parameters”
In this menu you manually configure the control parameters. If only the internal temperature is used as a
target value, the control parameters are entered only under “Internal”. If the process temperature is used
as the target value, also the internal controller can be used, for example, when reaching the set point limit
or in case of a Delta T limit. Consequently, parameter sets must be entered under all three items (“Inter-
nal”, “Jacket” and “Process”) when using the process temperature as a target value.
