19 MEGA Live Installation
7. Connect the Shaft Assembly to the Mounting Plate
1. Install the (4) 1/4-20 x 1" screws into the threaded holes on the steering
housing. Do not fully tighten.
2. Slide the bolts into the plate slots as shown in the illustration Connecting the
Steering Housing Assembly.
Connecting the Steering Housing Assembly
3. Hand-tighten the bolts using a 3/8" wrench. Hand tighten only!
