1 Introduction
Introduction
This manual will guide you through the following installation requirements for the
MEGA Live Imaging TargetLock transducer:
• Installing the Transducer and Foot Pedal
• Connecting to the Control Head and Power
• Testing the Installation
• Powering Off
Before proceeding with this installation, the Humminbird control head
and Minn Kota® Ultrex trolling motor should be installed. The MEGA Live
Imaging transducer can be connected directly to the control head or to
a Humminbird Ethernet Switch (optional, separate purchase required)
for networking. See the Ethernet Switch installation instructions to
install the Ethernet Switch.
Compatibility
Control Heads: MEGA Live Imaging TargetLock is compatible with all APEX™ Series
and SOLIX® Series fish finders, HELIX® Series G3N and G4N fish finders equipped
with MEGA Imaging+, and HELIX 7 G4N fish finders with MEGA Down Imaging or
MEGA Side Imaging. It can be mounted on Minn Kota Ultrex trolling motors.
Minn Kota Trolling Motor Humminbird Fish Finder
Minn Kota Ultrex APEX Series: All models
SOLIX Series: All models
HELIX Series: HELIX G3N and G4N models
with MEGA Imaging+ and HELIX 7 G4N
models with MDI or MSI
