2Introduction
Cables: Your MEGA Live Imaging transducer comes with the cables required to connect
directly to your APEX or SOLIX fish finder. In addition to the cables permanently
attached to the transducer, this includes two extension cables (a 10' MEGA Live power
cable and a 20' Ethernet cable) to allow for quick-disconnect. To connect the Ethernet
to a HELIX control head, you will need to purchase an ethernet adapter cable.
NOTE: An ethernet switch (separate purchase required) can be used to connect your
MEGA Live Imaging transducer to multiple control heads. To purchase accessories for your
control heads, visit our Web site at humminbird.com or
contact Humminbird Technical
Support through our Help Center at https://humminbird-help.johnsonoutdoors.com/
hc/en-us.
Accessories: Additional recommended accessories include a Humminbird Heading
Sensor GPS Puck (and a Heading Sensor GPS Adapter cable for APEX and SOLIX
only), or a Minn Kota Heading Sensor connected to an i-Pilot Link trolling motor.
A dual mount plate (separate purchase), is required to use a MEGA 360 Imaging™
transducer with your MEGA Live Imaging TargetLock.
For the most current list of compatible accessories, visit our Web site at humminbird.com.
Supplies
In addition to the hardware included with your accessory, you will need the
following supplies:
• 5A slow-blow fuse
• Philips head screwdriver
• 3/8 wrench or socket
• 1/2 wrench or socket
• Cable ties
• Minn Kota trolling motor Stabilizer Kit (included with each Minn Kota Ultrex
trolling motor or available as a separately purchased accessory)
• 1 Amp fuse (needed for MEGA 360 installation only)
• Allen wrench (needed for MEGA 360 installation only)
Switch (optional): If you do not have a main switch or fuse panel available on your
boat to connect power, you will need to purchase a battery switch. See Route the
Cables and Connect Power, Section 3: Connect Power for more information.
