29 MEGA 360 Installation
3. Install the Pod
1. Route the cables and up through the trolling motor mount and bracket.
2. Use an Allen wrench (not included) to install the (2) 10-32 x 9/16" socket bolts
on the bracket where the pod shaft is installed.
3. Tighten the bolts so the pod shaft is fully secure and won’t drop when it is
deployed in the next step. Hand-tighten only!
bracket
pod shaft
socket bolt holes
Routing the Cables and Pod Shaft
