25 MEGA Live Foot Pedal Installation
2. Position the base at the selected location and mark the mounting holes with a
pencil or similar marking tool.
NOTE: The base has three mounting holes that are used to secure it to the
boat. The bottom side of the base has three pads around the mounting holes.
These pads should be placed facing down when the base is installed.
3. Place one of the three (3) provided #8 screws in each of the mounting holes of
the base. Make sure the mounting holes still line up with the marked locations
and then use a drill with a #2 Phillips driving bit to secure the base to the deck
of the boat. Do not overtighten.
Securing the Base to the Deck
4. Once the base is installed, reattach the foot pedal to the base. Make sure the
tabs on the pedal click into place and that the pedal is fully seated on the deck
of the boat.
