5
PROC COMPONENTS CONTINUED
Main Display
Indicates various times, values,
and programmed information
Year Identies current calendar year
Month Identies current calendar month
Day Identies current calendar day
Start Time
Identies selected program
start time
Program Selector
Identies the program in use:
A, B, or C
Station Number
Identies currently selected
station number
Run Time
Allows user to set each valve
station run time from 1 minute
to 4 hours
Days of the Week
Identies days of the week
to water or not water
Odd/Even Watering
Identies if odd or even
watering days are selected
Interval
Identies if interval watering
has been selected
Seasonal Adjustment
Displays in increments of 5% the
selected percentage of seasonal
adjustments
Running Indicates when watering occurs
Rain Drop
Indicates watering will occur on
selected day
Crossed Rain Drop
Indicates watering will not occur
on selected day
A
LCD Display
B
Control Buttons and Switches
+Button
Increases the selected
ashing display
-Button
Decreases the selected
ashing display
→Button
Advances the selected ashing
display to the next item, also use
to start a manual cycle
←Button
Returns selected ashing display
to the previous item
PRG Button
Selects programs A, B, and C;
also use to start a test program
Rain Sensor
Bypass Switch
Use to bypass weather “Clik-type”
sensors if one is installed
