NOTE: A basic programming rule is that whatever
symbol or character is ashing will be the item
programmed. For instance, if the hour is ashing
when setting the time, the hour can be changed or
programmed. For illustration purposes in this manual,
ashing characters are in GRAY type.
The X-Core display shows the time and day when the controller is
idle. The display changes when the dial is rotated to indicate the
specic programming information to enter. When programming, the
ashing portion of the display can be changed by pressing the
or
buttons. To change something that is not ashing, press the
or buttons until the desired eld is ashing.
Three programs A, B, and C, each with the ability to have four daily
start times, permit plants with dierent watering requirements to be
separated on dierent day schedules.
PROGRAMMING THE CONTROLLER
Setting the Date and Time
1. Turn the dial to the CURRENT TIME/DAY position.
2. The current year will be ashing. Use the or buttons to
change the year. Aer setting the year, press the
button to
proceed to setting the month.
3. The month and day will be in the display. The month will be
ashing and the icon will be displayed. Use the or
buttons to change the month. Press the
button to proceed
to setting the day.
4. The day will be ashing and the icon will be displayed. Use
the or buttons to change the day. Press the
button to
proceed to setting the time.
5. The time will be displayed. Use the and buttons to select
AM, PM, or 24 hour. Press the
button to move to hours. Hours
will be ashing. Use the and buttons to change the hour
shown on the display. Press the
button to move to minute.
Minutes will be ashing. Use the and buttons to change
the minutes shown on the display. The date, day, and time have
now been set.
CURRENT TIME/DA Y
12
31
20
