Hunter XC User Manual

A– LCD Display
1. Run Times – Allows user to set each valve station run
time from 1 minute to 4 hours.
2. Start Times – Allows 1 to 4 start times to be set in
each program.
3. Station Number – Indicates currently selected station number.
4. Program Designator – Identifies program (A, B, or C) in use.
5. Day of the Week – Identifies day of the week
6. Interval Watering –Identifies month when programming current
date.
7. Odd/Even Watering – Identifies if Odd or Even watering has
been selected.
8. Flashing Sprinkler – Indicates that watering is taking place.
9. System Off – Allows user to discontinue all programs and
watering. Also allows the user to set the programmable "rain off"
which stops watering for a period from 1 to 7 days.
10. Umbrella – Indicates that the rain sensor is active.
11. Seasonal Adjustment – Allows the user to make run time
changes according to the seasons without reprogramming the
controller. Bars on the left allow quick visual reference to the
seasonal adjustment percentage.
12. Rain Drop – Indicates watering will occur on the selected day.
13. Crossed Rain Drop – Indicates the watering will NOT occur
on the selected day.
14. Calendar – Indicates interval watering schedule has been
programmed. Icon also appears when programming the current day.
B– WiringCompartment
15.Lithium Battery – The replaceable lithium battery (included) allows
the controller to be programmed in the absence of AC power. In
addition, the battery will provide power for backup timekeeping in the
event of a power outage.
16.Internal Junction Box – Junction box in outdoor models for
making AC power c
onnections.
18.
Terminal Strip
–
Use to attach transformer, sensor, and valve wires
from their source to the controller.
19.Reset Button – Use to reset the controller.
C – ControlButtons Button– Increases the selected item
flashing in the display.
Button – Decreases the selected item flashing in the display. Button
– Returns selected flashing display to previous item.
Button
–
Advances the selected flashing display to the next item.
Button – Selects program A, B or C for different watering zone
requirements.
19.
Sensor Bypass Switch.
Dial Settings
Run
–
Normal dial position for all controller automatic and manual
operation.
Current Time/Day– Allows current day and clock time to be set.
Start Times – Allows 1 to 4 start times to be set in each program.
Run Times – Allows user to set each valve station run time from 1
minute to 4 hours.
Water Days – Allows the user to select interval days to water.
Seasonal Adjustment – Allows user to make run time changes ac-
cording to the seasons without reprogramming the controller. Bars
on the left allow quick visual reference to the seasonal adjustment
percentage.
Manual-One Station– Allows user to activate a one-time watering
of a single valve.
Manual-All Stations – Allows user to activate a one-time watering
of all valve stations or a few selected stations.
System Off – Allows user to discontinue all programs and water-
ing. Also allows the user to set the programmable rain off which
stops watering for a period from 1 to 7 days.
D
–
External Transformer (Indoor Model only)
A plug in transformer
is provided to supply AC power to the controller.

Hunter XC Specifications

General

Application	Residential
Station Output	24 VAC
Warranty	2 years
Voltage	24 VAC
Watering Programs	3
Display	LCD
Programs	3
Start Times Per Program	4
Indoor/Outdoor	Indoor
Backup Battery	9V (not included)
Mounting	Wall mount
Transformer Input	120V AC
Transformer Output	24V AC
Seasonal Adjustment	Yes
Enclosure Rating	Indoor/Outdoor (with proper enclosure)
Power Source	Transformer (included)
Rain Delay	Yes, up to 7 days
