CARE
24
■ Method 1: This method
works best when the fabric
has been removed from the
headrail.
Insert the screwdriver
into the slot on the drive
assembly. Twist about
one-fourth turn to release
the spring-latch, and pull
down gently on the motor
assembly to separate.
■ Method 2: This method
works best when fabric
is still installed on the
headrail.
Insert a hex key into the
side slot on the drive
assembly (either front or
back) to release the spring-
latch, then pull down gently
on the motor assembly to
separate.
Remove the Headrail
■ With the fabric and motor removed, loosen
and push firmly up on the locking screws of
the mounting brackets until the locking tab
lifts from the headrail.
■ Rotate the headrail down as shown, until
the headrail pops free from the bracket.
Locking Tab
Locking
Screw
Loosen and Push Up
SofTrak
™
Headrail
1
Tilt Down
2
Twist to
Release
To Next Page
