Mount the Installation Brackets — Outside Mount
If you are mounting on corner or bay windows, refer to “Bracket Locations — Corner and Bay
Windows” on page 11 for specific bracket locations. Return to this page after identifying the
bracket locations.
■ Your order will include the appropriate number of installation bracket assemblies. The
number of assemblies required varies with headrail width, as shown below.
IMPORTANT: The spacer blocks have tabs that prevent the
brackets from being mounted too close to the ceiling. If the sheer
will not be mounted at ceiling level, the tabs can be removed.
Adding Clearance
■ Use spacer blocks to add additional clearance. Spacer blocks add clearance in
1
/
2
"
increments
.
➤ One spacer block is used with the faceplate for standard installation. Three additional
spacer blocks may be added for an extra 1
1
/
2
" clearance.
■ Use optional extension brackets to add more clearance.
➤ Extension brackets can provide up to 3
1
/
2
" clearance.
➤ Indentations are stamped into the extension brackets between each set of holes. Using
the indentations as a guide, you may cut off any unneeded length before mounting the
extension brackets. Each two-hole section is
1
/
2
" in length.
