CONTROLS 6
25
6.19 Closing 2-stroke oil tank cap
V01648-10
– Put the 2-stroke oil tank cap on and turn it clockwise.
–
Fold loop
1
down.
The 2-stroke oil tank cap engages.
6.20 Cold start button
S03529-10
The cold start button
1
is fitted on the side of the throttle valve
body.
If the engine is cold and the ambient temperature is low, the
electronic fuel injection system extends the injection time. To
help the engine burn the increased fuel quantity, it must be sup-
plied with additional oxygen by pulling the cold start button.
Info
If the engine is warm, the cold start button must be deac-
tivated.
Possible states
• The cold start button is activated – The cold start button is
pulled out all the way and turned by a ¼ turn.
• The cold start button is deactivated – A further ¼ turn
returns the cold start button back to the basic position.
