Align End Frames
NOTE THAT ALIGNMENT ORDER IS DIFFERENT FROM
TIGHTENING ORDER
! REFER TO THE ILLUSTRATION.
NOTE: Cases must be level before joining.
1. Insert alignment pin at lower front and lower
back.
2. Insert the alignment rod (
1
/4 in. diameter x
6 in.) through hole in top rail, align and insert
into second to rail.
3. Move the second case as close to the first as
possible by pushing or using lever bar (mule).
4. Match alignment pins with corresponding
holes in foam bottom and canopy.
5. In both holes in bottom shoe, place a 2 inch
neoprene washer between end frame and metal
washer of each case. Loosely assemble bolt,
washers, lockwasher and nut as shown on the
next page.
DO NOT TIGHTEN FULLY.
Do not attempt to draw cases together using
nut and bolt.
6. Insert a machine screw (#10 x 1
1
/4
in.)
through each hole in canopy end cap, align and
insert into joining canopy end cap. Fasten with
nuts. See detail below and on next page.
Do not tighten fully.
Location of #10 x 1
1
/4-in. machine screws
P/N 0501930_A 1-7
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Ultra Low Front
Rear Load Excel
Alignment Pin
