6.9.5. Self-diagnosis using Model eye
1. How to mount Model eye
(1) Remove chinrest paper.
(2) Mount Model eye as shown below and then fix it using two paper pins.
(3) Align the center of the Model eye with the objective lens using joystick and chinrest button.
2. Checking working distance
(1) Select FUNDUS measurement in MEASURE mode.
Chinrest button
Joystick
