HOCT-1/1F
(1) Set capture mode with the capture mode tabs ( ).
OCT/Fundus
(HOCT-1F only)
Capture OCT and fundus image simultaneously.
OCT
Capture OCT image.
Fundus (HOCT-1F only)
Capture Fundus image.
(2) Set capture region with the capture region combo box ( ).
OCT/Fundus
Macular, Disc, Anterior
OCT
Fundus
Single, Panorama
(3) In OCT or OCT/Fundus mode, set scan type and options for the selected scan region.
Scan region
Scan type
Available option
Scan along a line for macular.
Scan along horizontal lines and
vertical lines for macular.
Scan along 12 radial lines
centered at macular.
