BLADE TENSION ASSEMBLY COMPONENT LIST
ITEM QTY M-16 PART NUMBER M-20 DESCRIPTION
1 1 M16-421-00 M20-421-00 BLADE TENSION ARM
2 1 M16-422-00A M16-422-00A BLADE TENSION SHAFT ASSEMBLY
3 1 M16-3-03 M16-3-03 BUSHING
4 1 M16-3-04A M16-3-04A BUSHING
5 1 M16-4-11 M16-4-11 CAP
6 1 M16-4-12 M16-4-12 BOLT
7 1 7280 7280 PRESS IN GREASE FITTING
8 1 M16-3-02A M20-3-02A IDLER WHEEL SHAFT
9 4 S1-.5X1F S1-.5X1F SOCKET SET SCREW, FLAT POINT
10 1 M16-3-05 M16-3-05 1” NF HEX HEAD CAP SCREW
11 1 .5LOC .5LOC LOCK WASHER
12 1 B1-.5X2 B1-.5X2 HEX HEAD CAP SCREW
13 1 W19-45-01 W22-45-01 IDLER WHEEL
14 2 6309-2RS 6310-2RS BALL BEARING
15 1 W19-45-02 W22-45-02 IDLER WHEEL BEARING SPACER
16 1 HO-0393-PA HO-433-PA INTERNAL RETAINING RING, 3 9/16
17 1 M16-4-11 M16-4-11 DRIVE & IDLER WHEEL RETAINER
18 1 .5LOC .5LOC LOCK WASHER
19 1 B1-.5X1.5 B1-.5X1.5 HEX HEAD CAP SCREW
