5.1
ITEM QTY V18 PART NUMBER DESCRIPTION
1 1 V18-C4-00A HEAD CYLINDER
2 2 VW18-C3A-00B VISE CYLINDER
3 1 S25-C5-00 BLADE TENSION CYLINDER
4 1 V18L-C8-00 HEAD SWING BRAKE CYLINDER
5 (1) V18L-C6-00A GUIDE ARM CYLINDER
6 1 V18-C7A-00A HEAD SWING CYLINDER
7 (1)(2) V18-531-00 BUNDLING CYLINDER (option)
(1)(2) V18C-531-00 CANTED HEAD BUNDLING CYLINDER
8 (1)(2) V18-C10-00 LIFT ROLLER CYLINDER (option)
10 2 363290 VISE VALVES, DCV3P-AB-C
11 1 363290 BLADE TENSION VALVE, DCV3P-AB-C
12 1 363295 GUIDE ARM VALVE, DCV3P-AB-T
13 1 363295 HEAD SWING VALVE, DCV3P-AB-T
14 1 363290 CHIP AUGER VALVE (option), DCV3P-AB-C
15 3 363300 DOUBLE PILOT CHECK VALVE, DPCH-1
16 1 CHB-15C SWING CUSHION BLOCK
17 1 DDF5-0-00 DOWN FEED VALVE
18 1 MB6PA MANIFOLD BLOCK (6 position)
19 2(3) 360745 PRESSURE GUAGE (1000psi)
20 1 395410 CHIP AUGER MOTOR (option)
21 1 362745 PUMP
22 1 363110 SUCTION STRAINER
23 1 363105 RETURN FILTER
24 1 EB-01A EXTENSION BLOCK
25 1 JB-01B SINGLE JUNCTION BLOCK (VVP OPTION)
26 1 363150 PRESSURE REDUCING VALVE (VVP OPTION)
27 1 363160 SWING CUSHION VALVE
28 1 363160 HOLD VALVE
29 1 363305 PRESSURE REDUCING, blade tension
30 1 363305 PRESSURE REDUCING VALVE, head
V18 HYDRAULIC PARTS LIST
The V18 hydraulic system does not require any special work on a new machine before its start-up. The hydraulic tank is
lled with Texaco Rando HD 46 oil and all machine functions have been tested at the factory to ensure the proper opera-
tion upon start-up.
SECTION 5 - HYDRAULICS
