4.1
V18 COMPONENT LOCATION
The electrical schematics show some components labeled as TB1 to TB6 and these components are physically mounted
on DIN rails. The illustration below shows the location of the DIN rails with the installed components and the designated
TB number.
The following pages will show and explain in brief how to understand the correlation between the electrical schematic and
the control panel with regards to TB1 to TB6.
TB1 TB2
TB3
TB6
SECTION 4 - ELECTRICAL
