Hyd-Mech V18 User Manual

4.2
TERMINAL BLOCK 1
Page 4.1 shows the position of TB1 in the control panel. It can be seen that TB1 has only terminals mounted to it.
For example, if the electrical schematic shows a terminal, described as
This indicates that the terminal is located on din rail TB1 and is terminal #6.
would indicate that the terminal is mounted on TB1 and is terminal #25.
Terminals 1 - 33
TB1
6
TB1
25
TB1
6
TB1
25
