EDS 3000 IO-Link 13
Status: 2022-07-14 HYDAC ELECTRONIC GMBH Part no.: 669897
Designation
Representation
on
7-segment
display
ASCII
representation
Unit conversion
UN ,
Uni
Unit in bar
BAR
Bar
Unit in MPa
MPA
MPa
Unit in psi
PS ,
psi
Max. value
X ,
HI
Error indication
ERR
ERR
Display
D ,S
DIS
Reset
---
---
Yes
YES
Yes
No
NO
No
Reset max value
RS.XL
rS.HL
Programming disable
PR6
PrG
Keys locked
LOC
Loc
Keys unlocked
FREE
Free
Offset calibration
CAL,
cALi
New
NEU
nEU
Notes:
 If the current pressure exceeds the device's nominal pressure, it can no
longer be displayed, and the display begins to flash.
 If the actual pressure is less than 0.6 % of the nominal range, 0 bar is
displayed.
