Hydac ContaminationSensor CS1220 VIMS User Manual

ContaminationSensor CS1000 Trademarks
HYDAC Filter Systems GmbH
en
Page 2 / 36
CS1000 CAT-VIMS3478916 en 2009-04-15.doc 2009-04-15
Trademarks
The trademarks of other companies designate the products of those companies
exclusively.
Copyright © 2009 by
HYDAC Filter Systems GmbH
all rights reserved
All rights reserved. This manual may not be reproduced in part or whole, in any
form, without the explicit written agreement of HYDAC Filter Systems. Violations
shall be liable for damages.
Exclusion of liability
We have made every effort to ensure the accuracy of the contents of this document,
however we cannot rule out errors. We do not accept liability for any errors that may
exist nor for any damage or loss whatsoever arising as a result of such errors. The
content of the manual is checked regularly and the necessary corrections are
contained in subsequent editions. We welcome any suggestions for improvement.
All details are subject to technical modification.
The content of these instructions subject to revision without notice.
HYDAC Filter Systems GmbH
Servicetechnik / Filtersysteme
Industriegebiet
66280 Sulzbach / Saar
Germany
Phone: ++49 (0) 6897 / 509 – 01
Fax: ++49 (0) 6897 / 509 – 846

Hydac ContaminationSensor CS1220 VIMS Specifications

General

Type	Contamination Sensor
Category	Accessories
Application	Hydraulic and lubrication systems
Current consumption	Max. 100 mA
Operating temperature	-20°C to +60°C
Housing material	Stainless steel
Weight	Approx. 1.5 kg
Measuring principle	Light extinction
Particle size range	4 µm(c) to 70 µm(c)
Light source	Laser diode
Output Signal	4...20 mA
Operating voltage	10-30 VDC
Fluid temperature range	-20°C to +80°C
Protection class	IP67
Connection	M12
Communication	Modbus RTU
