39
No M-Code Finish signal Pusher movement sensor not
releasing ie dropping!
Check input X2 when pusher is
stationary once fed to Lathe’s turret
stop.
Possible movement device failure.
Push rod NOT feeding forward
after reload
1.No collet open signal! Check
input X17.
2.Lathe safety circuit not ready!
Check input X16.
3.Push command not active!
Check input X0.
Clamp collet/chuck to material.
Secure Lathe doors, select
Barfeeding mode.
Generate the feed request
command.
If; Push Rod aligned with centre of
spindle, check input X14!
If; Insert Pusher aligned with centre
of spinle, check input X15!
