Hydrafeed Multifeed 65 - Magazine Parts List

43
MXME - Multifeed Magazine Parts List
Part No Rev Description
MXME001 J One Piece Magazine
MXME001FL H Front Loading One Piece Magazine
MXME003 C Material Guide
MXME005 K Weld Assembly
MXME005FL J Front Loading Weld Assembly
MXME006 D Support Bracket
MXME007 C Guard End Plate
MXME008 C Guard Top Plate
MXME009 C Guard Weld Assembly
MXME010 C Safety Cover
MXME011 E Central Support
MXME012 D Link Plate
MXME015 G Central Support Weld Assembly
MXME016 F Central Support Assembly
MXME017 D Upper & Lower Support Tubes
MXME020 D Central Adjusting Screw
MXME021 D Lower Pivot Stud
MXME024 E Lower Link Plate
MXME028 A Front Loading Support Bracket
MXME031 B Weld Assembly of Magazine Central Adjusting Screw
MXME032 A Modification to Large Bevel Gear
MXME033 B Magazine Boss
MXME034 A Magazine Boss to Gear Assembly
MXME035 A Gear Housing
MXME036 A Gear Shaft
MXME037 A Gear Shaft Bush
MXME038 B Brass Washer
MXME039 A Small Bevel Gear to Housing Assembly
MXME040 C Half Depth One Piece Magazine
MXME041 C Half Depth One Piece Magazine Weld Assembly
MXME042 A Flat Bar Runner Half Depth
MXME043 A Modification to Magazine Fixing Bolt
MXME044 A Flat Bar Runner for Hexagon Bar
MXME045 C One Piece Magazine 1M Deep
MXME046 C One Piece Magazine 1M Deep Weld Assembly
MXME047 A Flat Bar Runner 1M Depth Magazine
MXME048 A Cradle Support Tubes
MXME049 A Support Tubes Weld Assembly
MXME050 B Support Tube Washer
MXME053 A Safety Cover
MXME054 A MX2 One Piece Magazine
MXME055 B MX2 One Piece Magazine Weld Assembly
MXME057 A MX1400 One Piece Magazine
MXME058 A MX1400 One Piece Magazine Weld Assembly
MXME059 A MX1400 Safety Cover
MXME060 A MX2 Guard Weld Assembly
MXME061 A MX2 Guard Top Plate
MXME062 A One Piece Magazine 500mm Deep
MXME063 A One Piece Magazine 500mm Deep Weld Assembly
MXME064 A Half Round Bar Runner
MXME065 A Half Round Bar Runner
